3.Outer Ring and Inner Ring Grooving Machine
To make the groove on the inner diameter of spiral wound gasket's outer ring.
Style
PX2000W
Outer ring grooving machine
Growing ring thickness
2-4mm
Maximum ring OD
4000mm
Minimum ring ID
200mm
Total power
2.2kw
Spindle motor power
0.55kw
Feed motor
0.04kw
Power supply
380v/220v for option,3 phases
Linear speed
0-mm/s
Machine measurement
950*800*1250mm
Machine net weight
320kg
